| Thread Rolling Machine - For Solid Bar |
| MODELS |
TR01-3T |
TR01-20 |
TR01-30D |
| SPECIFICATIONS |
|
|
|
| Thread Diameter (mm) |
0.8 ~ 12 |
5 ~ 22 |
6 ~ 40 |
| Pitch (P) |
0.4 ~ 1.5 |
0.75 ~ 2.5 |
0.75 ~ 3.0 |
| Maximum length of thread (mm) |
28 |
48 |
150 |
| Rotary die speed (rpm) |
40 |
40 |
40 |
| Maximum diameter or rotary dies (mm) |
100 |
120 |
150 |
| Bore diameter of rotary dies (mm) |
50.5 |
40 |
54 |
| Width of rotary dies (mm) |
30 |
50 |
150 |
| Maximum centre distance of die-spindled (mm) |
130 |
140 |
187 |
| Minimum centre distance of die-spindled (mm) |
90 |
100 |
140 |
| Output (pcs/min) |
20 ~ 40 |
9 ~ 30 |
7 ~ 20 |
| Height from table surface to die center (mm) |
85 |
118 |
130 |
| Motor (HP)3 phase, A.C. |
1 |
3 |
7.5 |
| Machine dimension(mm) |
800×600×750 |
1090×740×1070 |
1220x810x1120 |
| Packing dimension(mm) |
940×700×910 |
1245×850×1220 |
1365x925x1295 |
| N.W./G.W. (kgs) |
300 / 395 |
970 / 1130 |
1300 / 1480 |
